UST3127 widely used in the following applications:
Drilling Rig: Anchoring drill, water well drilling rig,Core drilling rig,jet drilling rig,down-hole drill,crawler hydraulic drilling rig,For poling Rig,trenchless drill etc.
Mechanical Engineering: Excavator,small pile driver,aerial work platform,small size loader etc.
Coal mine: Slag removing machine,underground drilling rig,Full hydraulic drilling rig,Hydraulic drill carriage and rock loading machine etc.
Mine: movable crusher,heading machine,conveying equipment etc.
Agricultural equipment: cane harvester,lawn mower,Ditching machine,etc.
| Part No. | UST3127 |
| Length | 3127mm |
| Width | 2450mm |
| Track Width | 500mm |
| Track Size | 500x154x43mm |
| Motor Displacement ml/r | 81/84 |
| Work pressure Mpa | 25 |
| Traction force KN | 132 |
| Travel speed km/h | 2.8/4.7 |
| Ground pressure Kpa | 59 |
| Max grade ability a° | 30 |
| Weight Kg | 4100 |
| Load Capacity Kg | 15000 |
| Pallet size | 3130*2650*1400mm |
| Warranty | One Year |
| Method | Hydraulic drive |
